Tube Filling Machine-MTF600
The Fully Automatic Tube Filling Machine MT600 combines versatility and durability, making it an ideal solution for a wide range of tube filling applications. Designed to handle round and oval tubes, with an optional maximum filling diameter of 60mm, the MT600 is characterized by its high versatility. Its unique cam type control system ensures high precision filling, from low to high viscosity materials, with a filling accuracy of ±0.5%. The MT600 offers excellent filling stability and mechanical durability, and can be upgraded with servo motor control for even greater accuracy.
Description
Product Overview
The Fully Automatic Tube Filling Machine MT600 combines versatility and durability, making it an ideal solution for a wide range of tube filling applications. Designed to handle round and oval tubes, with an optional maximum filling diameter of 60mm, the MT600 is characterized by its high versatility. Its unique cam type control system ensures high precision filling, from low to high viscosity materials, with a filling accuracy of ±0.5%. The MT600 offers excellent filling stability and mechanical durability, and can be upgraded with servo motor control for even greater accuracy.
Key Features
Versatile Tube Compatibility: Handles round and oval tubes (optional), with a maximum filling diameter of 60mm (optional), making it suitable for a wide range of types.
High Precision Filling: Unique cam type control system ensures high precision filling with an accuracy of ±0.5%, suitable for both low and high viscosity materials.
Durable and Reliable: Excellent filling stability and mechanical durability, with the option to switch to servo motor control for enhanced accuracy.
High Efficiency: Standard processing capacity of 60 tubes per minute, which can be further improved to 70 tubes per minute with optional configurations.
Easy Maintenance: Parts such as filling nozzles and cylinders can be maintained and cleaned without the need for tools, resulting in high production efficiency.
Optional Automatic Supply Device: The tube can be set with an optional automatic supply device (large capacity) to improve work efficiency.
Specifications
Model: MT600
Filling Capacity: Standard 60 tubes per minute, upgradable to 70 tubes per minute
Tube Material: Plastic, Laminate, Aluminum
Tube Shape: Round, Oval (optional)
Maximum Tube Diameter: Up to 60mm (optional)
Filling Volume Range: 5ml - 250ml
Filling Accuracy: ±0.5%
Control System: Cam type control (optional servo motor control)
Power Supply: 220V, 50/60Hz
Dimensions: 2300mm x 1200mm x 2000mm
Weight: 900kg
Compliance: FDA-approved materials for product contact parts
Applications
The Fully Automatic Tube Filling Machine MT600 is versatile and can be used in various industries, including:
Cosmetics: Ideal for filling creams, gels, lotions, and other cosmetic products.
Pharmaceuticals: Perfect for filling medicinal creams, ointments, and gels.
Food & Beverage: Suitable for filling food pastes, sauces, and other edible products.
Chemicals: Can be used for filling various chemical products, including adhesives and sealants.
